Edelbrock 60519 - Edelbrock Oldsmobile Performer RPM Cylinder Heads



Edelbrock 60519 - Edelbrock Oldsmobile Performer RPM Cylinder Heads

JEGS Part Number: 350-60519

Oldsmobile Performer RPM Cylinder Head
  • 1965-76 400-455ci
  • 188cc Intake Ports
  • 77cc Combustion Chambers
  • 2.072"/1.68" Valves
  • 1.46" Valve Spring Diameter
  • Max Lift: .575"
  • 7/6" Rocker Studs
  • Assembled, Sold Each
  • $1,029.50
    Ships
    FREE Shipping

    Edelbrock 60519 - Edelbrock Oldsmobile Performer RPM Cylinder Heads Details

    Oldsmobile Performer RPM Aluminum Cylinder Heads

    Recommended intake gasket is Mr Gasket #720-404.
    Aftermarket 7/16'' stud rocker arms and 3/8'' hardened pushrods required.

    Tech Tip: To gain more spark plug clearance, Edelbrock recommends using Champion RC Series plugs such as the RC12YC (P/N 192-49776). They are 0.230'' shorter than a conventional spark plug and have a 5/8'' hex for easier access.

    Specifications:

    Type
    Complete
    Emission
    Non-Emissions
    Engine Make/Size
    Olds 400-455
    Usage
    Street/Performance
    Engine Make/Size
    Olds 350-403
    Cylinder Head Type
    Standard
    Preparation
    Bolt On (Not Required)
    Finish
    Cast Aluminum
    Accessory Bolt Holes Drilled
    Yes
    Calculator
    Compression Calculator
    CNC-Machined Combustion Chamber
    No
    CNC-Machined Exhaust Runner
    No
    CNC-Machined Intake Runner
    No
    Combustion Chamber Style
    Heart
    Combustion Chamber Volume (cc)
    77
    Cylinder Head Finish
    Natural
    Cylinder Head Material
    Aluminum
    Cylinder Head Style
    Assembled
    Damper Spring Included
    Yes
    Exhaust Port Location
    Standard
    Exhaust Runner Volume (cc)
    106
    Exhaust Valve Diameter (in.)
    1.68
    Exhaust Valves Included
    Yes
    Guideplates Included
    Yes
    Heat Crossover
    No
    Intake Port Location
    Standard
    Intake Runner Volume (cc)
    188
    Intake Valve Angle
    18
    Intake Valve Diameter (in.)
    2.072
    Intake Valves Included
    Yes
    Lock Style
    7 degree
    Locks Included
    Yes
    Machined for O-Ring
    No
    Maximum Valve Lift (in.)
    0.575
    Number of Springs Per Valve
    Single
    Oiling Style
    Through pushrod
    Outside Diameter of Outer Spring (in.)
    1.46
    Quantity
    Sold individually
    Retainer Material
    Steel
    Retainers Included
    Yes
    Rocker Arm Nut Thread Size (in.)
    7/16"-20
    Rocker Arm Nuts Included
    No
    Rocker Arm Studs Included
    Yes
    Rocker Arms Included
    No
    Steam Holes Drilled
    No
    Valve Cover Mounting Style
    Perimeter bolt
    Valve Guide Material
    Manganese bronze
    Valve Guides Included
    Yes
    Valve Seat Machine Style
    3-angle
    Valve Seat Material
    Ductile iron
    Valve Seats Machined
    Yes
    Valve Springs Included
    Yes
    Valve Stem Seal Style
    Positive stop
    Valve Stem Seals Included
    Yes
    Manufacturer's Part Number:
    60519

    Designed for high-performance non-emission 1965-76 Oldsmobile 400, 425 and 455 cubic-inch engines with Torker 455 manifold #350-2730. This head features an improved 77cc combustion chamber design that increases the quench area for a more efficient burn. This results in outstanding horsepower and torque.

    These complete heads are assembled and ready-to-run with stainless steel 2.072'' intake valves and 1.680'' exhaust valves, hardened ductile iron valve seats and phosphor bronze guides. The valvetrain has been upgraded from the factory pedestal-mount system to a 7/16'' screw-in stud and 3/8'' pushrod-slot guideplate for increased valvetrain stability.

    The high-velocity, factory location ports feature 188cc intake runners and 106cc raised-floor exhaust runners for substantially improved flow and increased power. Head bolt holes are drilled for the stock 7/16'' bolts, but can be easily modified for 1/2'' bolts or studs by drilling the 1/2'' counterbore. Aftermarket rocker arms and hardened pushrods are required for installation. These heads will fit 350-403 Oldsmobiles with Edelbrock manifold #350-7111 only (port matching required). Made In The USA!



    Features:
  • Combustion Chamber Volume: 77cc
  • Intake Runner Volume: 188cc
  • Exhaust Runner Volume: 106cc
  • Intake Valve Diameter: 2.072"
  • Exhaust Valve Diameter" 1.68
  • Valve Stem Diameter: 11/32"
  • Valve Guides: Manganese Bronze
  • Deck Thickness: 5/8"
  • Valve Spring Diameter: 1.46"
  • Valve Spring Maximim Lift: .575"
  • Rocker Stud: 7/16"
  • Guideplate: Hardended Steel
  • Pushrod Diameter: 3/8"
  • Valve Angle: 18&
  • Exhaust Port Location: Stock
  • Spark Plug Fitment: 14mm x 3/4 Reach, Gasket Seat
  • Made In The USA!
