Performer RPM FE Aluminum Heads
Note: 72cc chamber heads have both vertical and diagonal exhaust bolt patterns. 76cc heads have vertical exhaust bolt pattern only.
Tech Tip: To gain more spark plug clearance, Edelbrock recommends using Champion RC Series plugs such as the RC12YC (P/N 192-49776). They are 0.230'' shorter than a conventional spark plug and have a 5/8'' hex for easier access.
Combustion Chamber Volume: | 72cc |
Intake Runner Volume: | 170cc |
Exhaust Runner Volume: | 125cc |
Intake Valve Diameter: | 2.09'' |
Exhaust Valve Diameter: | 1.66'' |
Valve Stem Diameter: | 3/8" |
Valve Guides: | Manganese bronze |
Deck Thickness: | 5/8'' |
Valve Spring Diameter: | 1.55" |
Valve Spring Maximum Lift: | .600" |
Rocker Stud: | N/A |
Guideplate: | N/A |
Pushrod Diameter: | 3/8 |
Valve Angle: | 13° |
Exhaust Port Location: | Stock |
Spark Plug Fitment: | 14mm x 3/4'' Reach, Gasket Seat |
Valve Lift | Intake | Exhaust |
.100'' | 88 | 64 |
.200'' | 153 | 113 |
.300'' | 195 | 148 |
.400'' | 233 | 171 |
.500'' | 265 | 183 |
.600'' | 270 | 200 |
.700'' | N/A | N/A |
Flow Numbers as tested by Edelbrock's SuperFlo SF-1020 flow bench @ 28'' H2O |
Emissions Note:
This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.
CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART
Specifications:
These heads have valves for a hydraulic lifter roller rockers where can I get a non adjustable rocker shaft suitable for this head and my hydraulic lifters?
Will the 60065 cylinder heads work with roller camshaft?
