Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Part TypeAxle Hub Assembly
BrandACDELCO
Package Height6.88
Package Width117
Package Length9.62
Weight14.77
Wheel Pilot Diameter3.94
Flange Bolt Hole Diameter12.5
Good Maintenance Practices - Section 1 - Bullet 1Be sure to have the bearing properly aligned when pressing it into the spindle assembly and do not overtighten center hub bearing to constant velocity shaft nut.
Terminal GenderMale
Good Maintenance Practices - Section 1 - Bullet 2Follow the manufacturers recommended torque specification.
Product DescriptionACDelco GM Original Equipment Wheel Bearings allow the wheel to rotate with minimal friction, and are GM-recommended replacements for your vehicle's original components. Wheel bearings support the weight of the vehicle and are lubricated with axle oil or wheel bearing grease. These original equipment wheel bearings have been manufactured to fit your GM vehicle, providing the same performance, durability, and service life you expect from General Motors. ⚠<b> WARNING:</b> Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Connector Quantity1
Brake Pilot Diameter178.4
Spline Quantity33
Flange Bolts IncludedNo
Bolt Circle Diameter139.7
Length (In)9.62
Flange Diameter7.02
Anti Lock Braking SystemYes
Flange IncludedYes
Outside Diameter7.01
Flange Offset50.2
Part CategoryReplacement Parts
Programming RequiredNo
Flange ShapeTriangular
Signs Of Wear &#38; Troubleshooting - Section 1 - Bullet 1Grinding or humming noise from bearing assembly maybe more noticeable while turning
Signs Of Wear &#38; Troubleshooting - Section 1 - HeaderSigns of wear for wheel bearings include but are not limited to:
Connector Terminal Quantity2
Wheel Stud Size0.47
Wheel Stud Quantity6
Anti Lock Braking System TypeSensor
Features &#38; Benefits - Bullet 6GM-recommended replacement part for your GM vehicle's original factory component
Features &#38; Benefits - Bullet 7Offering the quality, reliability, and durability of GM OE
Inside Diameter1.47
Features &#38; Benefits - Bullet 8Manufactured to GM OE specification for fit, form, and function
Features &#38; Benefits - Bullet 2Supports the weight of the vehicle
Meets Or Exceeds Original Equipment Manufacture SpecificationsYes
Features &#38; Benefits - Bullet 3Maximum lateral stiffness for optimum ride, handling, and driving dynamics
Features &#38; Benefits - Bullet 4GM OE parts are built to help withstand potholes and designed to maximize seal life
Features &#38; Benefits - Bullet 5GM OE bearing designs are dimensionally optimized to work with their mating parts
Features &#38; Benefits - Bullet 1Allows the wheel to rotate with minimal friction
Bearing TypeBall
Wheel Studs IncludedYes
Flange Bolt Hole Quantity3
Connector GenderFemale
Hub Pilot Diameter (In)3.911
Hub Pilot Diameter (Mm)99.34
Height (In)6.88
Signs Of Wear &#38; Troubleshooting - Section 1 - Bullet 2Tire and wheel vibration
Signs Of Wear &#38; Troubleshooting - Section 1 - Bullet 3Excessive play at tire and wheel
Signs Of Wear &#38; Troubleshooting - Section 1 - Bullet 4Wheel hot to the touch
Part FitmentDirect Fit
Grade TypeOE
Vendor Part NumberFW369
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
