How to Read My Sidewall

Arroyo AR 1000 is a premium, fuel-efficient steer and all-position TBR tire designed for long-haul efficiency and durability. A specialized tread compound minimizes rolling resistance to help maximize fuel economy, while five straight ribs with closed shoulders maintain constant road contact for stable handling and long, even wear. Siping, cross grooves, and wavy channels at the base of the grooves work together to improve wet traction, rounding out a tire built for reliable, cost-effective performance on the road.

Arroyo Tire A1K006 AR1000 STEER Tire, 11R24.5 [Blackwall] Features:

• Tread Depth: 17.64 in./32nds
• Section Width: 10.98 in.
• Tread Width: 220 mm
• Overall Diameter: 43.46 in.
• Max Load Single (lbs.): 7160
• Minimum Recommended Wheel Width: 7.50 in.
• Maximum Recommended Wheel Width: 8.25 in.
• Ply: 16(H)
• Maximum Inflation Pressure: 120
