Arroyo AR4000 is a trailer tire engineered for durability and long-term value. Its shallow tread design reduces the rate and risk of irregular wear, while a casing construction matching that of other wheel-position tires boosts retreading value even on a non-dynamic axle. Serrated rib edges relieve stress and multiple sipes support excellent long-term wear performance, while serpentine, graduated groove walls promote tread self-cleaning to maintain grip in mud and dirt. Altogether, the AR4000 delivers a reliable, cost-effective solution built specifically for trailer applications.

Arroyo Tire AR4K03 AR4000 Trailer (Long Haul) Tire, 11R24.5 [Blackwall] Features:

• Tread Depth: 12.98 in./32nds
• Section Width: 10.98 in.
• Tread Width: 212 mm
• Overall Diameter: 43.46 in.
• Max Load Single (lbs.): 6610
• Minimum Recommended Wheel Width: 7.50 in.
• Maximum Recommended Wheel Width: 8.25 in.
• Ply: 14G
• Maximum Inflation Pressure: 105
