Notes:

• Tinware includes timing cover, oil pan, and valve covers
• VIN 1
• Head Cast #: 3L8E-BB, YF1E-FC, YL8E-BB
• Block Cast #: XW4E, 4F1E-AA
• Timing Cover Cast #:: 1S7E
• Must reuse or supply their own oil cooler
• 24 valves

Engine Break-In Procedure

Use conventional or break-in oil (non-synthetic) for the first 600 miles of operation. Do not drive for long periods at any single speed, always vary your speed. Do not tow a trailer or put other heavy loads on the vehicle. Check the engine oil and coolant levels daily.

At 600 Miles change the engine oil and filter using conventional (non-synthetic) oil. Check fuel and ignition settings; adjust valves (where applicable).

After the first 5,000 of service synthetic engine oil may be used. Follow your vehicle owner’s manual for service intervals.
