Features:

• Highly responsive and accurate electric air-core gauges
• Black textured finish
• Direct fit replacement, no need to modify dash

Includes:

American Muscle Speedometer Gauge

• 5 in. diameter
• Lit LCD odometer
• LED through-the-dial lighting provides clear visibility during nighttime use
• Capable of registering one-million miles with two resettable trip odometers
• Simple push-button, 2 mile drive calibration - no dip switches
• Easy to reprogram to accommodate changes in gear ratio or wheel and tire combination
• Works with most two wire sine wave and three wire hall effect vehicle speed sensors
• 160 MPH Range

American Muscle Tachometer Gauge

• 5 in. diameter
• Compatible with 1 - 4 pulse ignition signals
• LED through-the-dial lighting provides clear visibility during nighttime use
• Works with 1-4 pulse ignition singals, (2-8 cylinder engines) with points, electronic, and most 12V high-performance racing ignitions
• Compatible with 12 and 16 volts, allowing use on most street or race car with electrical system
• 8K RPM Range

American Muscle Water Temperature Gauge

• 2-1/16 in. diameter
• LED through-the-dial lighting provides clear visibility during nighttime use
• Compatible with 12 and 16 volts, allowing use on most street or race car with electrical system
• 100-250 degrees F Range

American Muscle Oil Pressure Gauge

• 2-1/16 in. diameter
• LED through-the-dial lighting provides clear visibility during nighttime use
• Compatible with 12 and 16 volts, allowing use on most street or race car with electrical system
• 100 PSI Range

American Muscle Fuel Level Gauge

• 2-1/16 in. diameter
• LED through-the-dial lighting provides clear visibility during nighttime use
• Compatible with 12 and 16 volts, allowing use on most street or race car with electrical system
• 0-90 ohms

American Muscle Voltmeter Gauge

• LED through-the-dial lighting provides clear visibility during nighttime use
• Compatible with 12 and 16 volts, allowing use on most street or race car with electrical system
• 8-18 Volt Range

______________________________

• 1/8 in. NPT Water Temperature and Oil Pressure Senders with 1/4 in., 3/8 in., and 1/2 in. NPT Adapter Fittings
• 6-Gauge Wire Harness
• Electric Speed Sensor
• 3 Optional LED Indicators (2 Green, 1 Amber)
• Cutouts for OEM controls, air vents, and radio (where applicable)
• Installation Instructions
