Features:

• Gas and gasless functionality
• Synergic control feature
• Portable
• Weighs 22 lbs.
• Adaptive advanced single IGBT technology for increased reliability
• Fits standard 2 lb. (1 kg) and 11 lb. (5 kg) spools
• Welds steel, stainless steel, copper, and aluminum
• Includes integrated MIG torch, ground clamp, and stinger

Specifications:

• Power supply voltage: 120 +/- 10%
• Rated input capacity: 6
• Frequency (inverter): 45
• Rated input current: 45/24.6
• Electrode type: 6013, 7018
• Wire diameter: .023 in. - .035 in. (1/16 in. - 1/8 in.)
• No-load voltage: 51
• Efficiency: 80
• Power factor: 0.75
• IP: 21 S
• Insulation class: H
• Cooling: Fan and Air
• Dimensions: 20 in. x 6 in. x 11.500 in. (430 mm x 150 mm x 290 mm)
• Net weight: 22 lbs.

MIG Function:

• Output current range: 50-140
• Duty cycle @ 104 degrees F (40 degrees C) for 10 minutes:
  • 140 Amp - 30%
  • 108 Amp - 60%
  • 76 Amp - 100%

MMA (Manual Metal Arc) Function:

• Output current range: 10-120
• Duty cycle @ 104 degrees F (40 degrees C) for 10 minutes:
  • 120 Amp - 30%
  • 192 Amp - 60%
  • 65 Amp - 100%
