Blueprint Engines are a great choice for drivable and reliable high performance engines. All rotating assemblies are balanced within 2 grams on a computerized balancer. Blueprint Engines are dyno tested and include dyno sheets.
Best of all they feature a 30 month/50,000 mile warranty.

Recommended Stall Converter: 2000-2400 rpm
Recommended Fuel: 91 Octane

Block:

• 4-bolt main block
• 1-Piece rear main seal
• Square and parallel decked
• Align honed main bearing bore
• Cylinders are sonic tested for thickness
• Cylinders honed on a computer controlled machine to within .0002'' straightness and roundness

  Rotating Assembly:
• Cast crankshaft
• 1-piece rear main seal
• Chevy heavy beam rods with 150,000 PSI bolts
• Flat top hypereutectic pistons; 9.5 to 1 Compression
• Hastings Moly rings
• Balanced rotating assembly
• Roller camshaft
• Roller rockers
• Melling high volume oil pump
• Heavy duty double roller timing set

  Cylinder Heads:
• New cast iron Vortec heads
• 1.25 diameter valve springs
• Hardened retainers and valve springs
• 2.02'' swirl polished intake valves
• 1.60'' swirl polished exhaust valves
• Hardened push rods

  Camshaft Specs:
• Hydraulic Roller
• Duration @ .050'' Lift: 236 Intake / 242 Exhaust
• Lift: .520'' Intake / .540'' Exhaust

  Other Features:
• Performance aluminum dual plane satin intake manifold
• New chrome valve covers
• Brass freeze plugs

  Dress Model Adds:
• Holley 750 cfm Manual Choke Vacuum Secondary Zinc Carburetor - 510-0-3310S
• Distributor and coil
• Professional Products balancer
• Edelbrock 110GPH fuel pump
• Edelbrock satin water pump
• MSD plug wires
• AC Delco spark plugs



  ---




  Note: Your BluePrint engine was dyno tested with the parts and specifications listed below. If you prefer to install a different part, your engine may not produce the horsepower recorded on your dyno sheet.

• Part Number: BP3833CT1
• Fuel Delivery Type: Carbureted, 750cfm ** Not included**
• Spark Plug: AC Delco 41-993
• Spark Plug Gap: .045"
• Harmonic Balancer: 400 ci weighted, 8" diameter
• Flexplate/Flywheel: Late 350 Weighted
• Stall Converter: 2000-2400 rpm
• Intake Manifold: Dual plane, satin aluminum
• Fuel Recommendation: 91 Octane
• Timing (Initial/Total Advance): Initial timing - 10-16° and Total timing 32-34°
• Firing Order: 1-8-4-3-6-5-7-2

JEGS Easy Kits are designed by JEGS high performance racing professionals to help you get all the performance parts you need for your race car, hot rod or truck.
