L96 6.0L TECH SPECS:

• Engine Type: LS-Series Gen IV V8 Small Block
• Displacement: 364ci (6.0L)
• Bore x Stroke: 4.000" x 3.622" (101.6mm x 92mm)
• Block: Cast-iron with 6-bolt cross-bolted main caps
• Crankshaft: Nodular Iron with 6-bolt flange
• Connecting Rods: Powdered metal
• Pistons: Hypereutectic aluminum with polymer coating, floating wrist pins
• Camshaft Type: Hydraulic roller (12626660)
• Camshaft Duration at .050": 193° Intake / 200° Exhaust
• Cylinder Heads: Aluminum L76/L92
• Valve Size: 2.00" Intake / 1.56" Exhaust
• Compression Ratio: 9.6:1
• Rocker Arms: 1.7:1 Ratio, Investment Cast, Roller Trunnion
• Recommended Fuel: Regular unleaded pump
• Maximum Recommended RPM: 6000
• Reluctor Wheel: 58X
• Balance: Internal

INSTALLATION NOTES:

• Includes electronic throttle body
• Not intended for marine applications
