Large Port Cast Iron Vortec Bare Cylinder Head 225cc Intake Ports
- Large Port Cast Iron Vortec Cylinder Head
- 225cc Intake Ports
- 77cc Exhaust Ports
- 65cc Combustion Chambers
- Bare, Each
Specs: - 66cc combustion chambers.
- 0.450" deck thickness.
- Hardened exhaust valve seats.
- Machined for 2.000"/1.550" valves.
- Straight spark plug design.
- No heat risers.
- Drilled and tapped for 7/16"-14 screw-in studs.
- Dual bolt patterns for perimeter-style and center-bolt valve covers.
America's favorite high-performance cast iron small block cylinder heads offer big power and bigger value. Chevrolet Vortec Cylinder Heads' fast burn combustion chamber and high-velocity ports combine to produce big horsepower. Vortec Heads can be mildly ported for additional performance and milled up to .040'' for increased compression ratio. The Vortec Heads come with various intake and exhaust valve sizes to complement the high-velocity port design and your performance needs. Vortec Heads outflow Bow Tie Heads right out of the box and are a 20 to 40 horsepower bolt-on increase over earlier cast iron small block heads.
Show More
Vortec Heads require a Vortec-style intake manifold due to an improved manifold mounting flange and gasket design and raised intake ports. Modifying the heads to accept early intake manifolds is not recommended. Vortec Cylinder Heads fit all 1955-Present small blocks except LT1/LT4 reverse coolant flow engines and current LS1-style engines.
