LT4 SC 376ci / 6.2L TECH SPECS:

• Engine Type: Direct injection spark ignition Gen V Small-Block V8
• Displacement: 376ci (6.2L)
• Bore x Stroke: 4.065' x 3.622' (103.25 x 92mm)
• Block: Cast aluminum with 6-bolt nodular iron main bearing caps
• Crankshaft: Forged steel
• Connecting Rods: Forged powdered metal
• Pistons: Forged aluminum
• Compression Ratio: 10.0:1
• Camshaft Type: Hydraulic roller
• Valve Lift: .492' intake/ .551' exhaust
• Camshaft Duration (@.050 in.): 189° intake / 223° exhaust
• Cylinder Heads: A356T6 Rotocast Aluminum, Direct Injection; as cast w/ 65.5cc combustion chambers
• Valve Size: 2.130' intake / 1.590' exhaust
• Rocker Arms: Investment-cast, roller trunnion
• Rocker Arm Ratio: 1.81:1
• Recommended Fuel: Premium pump
• Maximum Recommended RPM: 6600
• Reluctor Wheel: 58X
• Balanced: Internal

INSTALLATION NOTES:

• Intended for pre-1976 street vehicles or any off-road vehicle
• 8-bolt crankshaft flange
• Not intended for marine applications
• Dry-sump engine requires production or aftermarket oil lines and external oil tank (not included)
• Dry-sump engine comes with a Corvette oil pan. Use oil hose adapters (p/n 809-25534412) to adapt -12 AN fittings
