Vehicle Info NeededCLEVITE MAHLEPART NUMBER: 695-2243413030
Piston Set 1999-2005 Ford Modular V8 4.6L SOHC with 3.582" Bore (+.030")
$31368
Ships on 09/16/2026
Lowest Price GuaranteeFord
- Piston Set
- 1999-2005
- Ford Modular V8 4.6L SOHC
- 3.582" Bore (+.030")
- Coated Skirt
- Set of 8
- Rings Not Included
Technical Specs: - Material: Aluminum
- Bore: 3.582' (90.98mm)
- Compression Height: 1.216"
- Compression Ring Groove: 1.50mm
- Second Ring Groove: 1.50mm
- Oil Ring Groove Width: 3.00mm
- Full Length: 2.036" (51.714mm)
- Pin Size: 0.866" O.D. (22.0mm)
- Pin Type: Floating
- Skirt Type: Coated
- Piston Skirt Clearance: 0.001"
- Year Range and applicable VIN code: CAR - 1999-2003 "X" "W" "9"; TRUCK - 1999-2000, 2002-2003 "6"
Part TypePiston
BrandCLEVITE MAHLE
Package Height5.6
Package Width5.6
Package Length6.2
Weight1.16 PG
Part CategoryReplacement Parts
Vendor Part Number2243413030
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
