Vehicle Info NeededCOLD CASE RADIATORSPART NUMBER: 359-FOM564
Aluminum Performance Radiator 1964.5-1966 Ford Mustang
$38554
1 left in stock
Ships Tomorrow
Lowest Price GuaranteeFord Mustang
Aluminum Performance Radiator1964.5-1966 Ford Mustang 289 Manual Transmission 16.5" H x 16.85" W x 3" L
Cold Case Radiators FOM564 Features:
1964.5-1966 Ford Mustang 289 Aluminum Performance Radiator. MT Cars. These COLD-CASE radiators are Tig welded 100 percent aluminum and absolutely beautiful. Don't buy a 3 or 4 row aluminum radiator! It doesn't cool as good as these oversize 2 row models. Original fan shroud will mount with original mounting brackets.These radiators are original appearing and have the correct stamping. Once painted, you'd be hard pressed to find a difference over an original versus a COLD-CASE.100 percent TIG weldedAll AluminumPolished OE style tanks16 fins per inchCorrugated fins that give more surface area and more thermal transferPressure testedFor manual transDirect fitment for 64.5-66 Mustang w/ 289 V8Old Part Number: RPE564Radiator SpecsCore Height 16.5 inchCore Width 16.85 inchOverall Height 21 inchOverall Width 19.6 inchOverall Thickness 3 inchTubes (2) 1.25 inch TubesPerformance Replacement Radiators
When it's time to replace the radiator or perform an engine swap in your car or truck, check out Cold Case ready-fit aluminum performance radiators. Providing exceptional flow with oversized dual-row design performing better than traditional 3-4 row radiators, but at a lower price. Every Cold Case radiator is TIG-welded and built to OE standards for outstanding appearance, a flawless fit, and long-lasting performance.
Part TypeRadiator
Product LineCold Case Aluminum Radiators for Ford Vehicles
BrandCOLD CASE RADIATORS
Package Height8.5
Package Width28.0
Package Length32.0
Weight22.0 PG
Part CategoryPerformance Parts
Overall Thickness3 in (76.2 mm)
Overall Height21 in (533.4 mm)
Outlet Size1.75 in (44.5 mm)
Radiator Cap IncludedYes
Radiator MaterialAluminum
Inlet Size (In.)1.5
Core Height16.5 in (419.1 mm)
Core Width16.875 in (428.625 mm)
Row Quantity2
Overall Width19.5 in (495.3 mm)
Tube Size1 in (25.4 mm)
Fan IncludedNo
Transmission CoolerNo
Radiator StyleDownflow
Vendor Part NumberFOM564
Package Qty1
Package TypeEA
