Comp Cams Oval Track Camshafts
InfoVehicle Info Needed
COMP CAMSPART NUMBER: 249-12-653-5

Comp Cams Oval Track Camshafts

$21699
ShippingShips Tomorrow
Lowest PriceLowest Price Guarantee

Small Block Chevrolet 262-400ci 1955-1998
  • Mechanical Flat Tappet - (Xtreme Oval)
    • Oval Track Mechanical Flat Tappet Camshaft
      Chevrolet 262-400ci 1955-1998
      Lift: .540"/.531"
      Duration: 282°/288°
      Lobe Separation Angle: 106°
      RPM Range: 3200-7000

    • Oval Track Camshaft
    • 1 Year Limited Warranty

      265, 283, 307, 302, 305, 327, 350, 383, 400, 427, L46, L48, L65, LM1, LT-1, L82, L81, LS9, L83, L98, L05, LG3, LG4, LT1, LT4, Camaro, Corvette, Chevelle, Stingray, Silverado, C10, Firebird, Chevrolet, Chevy, Small Block Chevy, Caprice, Malibu, Impala, Nova, 355, GEN1, Monte Carlo, S10


      1/4-3/8 fast. 327-358c.i., 11:1+ compression. 2 BBL with good intake and exhaust.

    Comp Cams Oval Track Camshafts are specifically designed for oval track racing. These cams are available for a variety of engine configurations, track lengths, and conditions so there's sure to be one to meet your needs.

    Show More

    Features:

    • Wide assortment of racing camshafts for all application requirements of drag, oval track and puller & mud competitors
    • Require accurate assessment of rear end gearing and other vehicle-based equipment to deliver top performance
    • Not made for street use or vehicles requiring accessory drive equipment, such as power brakes, air conditioning, etc.

    When performance and consistency are the difference between taking the checkered flag or falling behind, Comp Cams Oval Track Camshafts are built to deliver the edge serious racers need. Designed specifically for dirt and paved short-track racing, these camshafts are engineered to provide a powerful combination of throttle response, torque, and top-end power across a wide RPM range.

    Each oval track camshaft is precision-ground to optimize valve timing and lift for high-compression small block engines—particularly where quick acceleration out of corners and strong mid-range pull matter most. Whether you're racing in IMCA, UMP, or other local and national series, these cams provide the aggressive performance needed to stay ahead of the pack.

    Built with endurance in mind, the dirt track camshaft options offer exceptional durability and consistency lap after lap, even in the most demanding race conditions. From slick clay to tight asphalt corners, these camshafts help deliver the dependable horsepower and torque necessary for quick launches and smooth gear transitions.

    For racers running a Small Block Chevy engine, the circle track camshaft SBC options are tuned for peak performance within racing rule sets, giving you the competitive advantage without compromising reliability.

    Upgrade to Comp Cams Oval Track Camshafts and dominate every lap with proven race-winning performance. Available now at JEGS—your trusted source for serious racing parts.

    Part TypeCamshaft
    Product LineComp Cams Oval Track Camshafts
    BrandCOMP CAMS
    Package Height2.8
    Package Width2.9
    Package Length24.2
    Weight9.1 PG
    Part CategoryPerformance Parts
    Exh. Duration @ .050 In. (Deg)254
    Cam StyleMechanical flat tappet
    Grind Number282XOS
    Exh. Duration Advertised (Deg)288
    Engine Make/SizeChevy Small Block (262-400)
    Intake Valve Lift With Factory Rocker Arm Ratio (I0.54
    Int. Duration @ .050 In. (Deg)252
    Basic Operating Rpm Range3,200-7,000
    Intake Valve Lash0.016 in (0.406 mm)
    Intake Valve Lift0.54 in (13.716 mm)
    Computer-Controlled CompatibleNo
    Int. Duration Advertised (Deg)282
    Lobe Separation (Deg)106
    Rpm Range3200-7000
    Advertised Duration282 int./288 exh.
    Exhaust Valve Lift With Factory Rocker Arm Ratio (0.531
    UsageStrip
    Valve Lift With Factory Rocker Arm Ratio0.540 int./0.531 exh.
    QuantitySold individually
    Exhaust Valve Lash0.018 in (0.457 mm)
    Exhaust Valve Lift0.531 in (13.487 mm)
    Advertised Intake Duration282
    Intake Duration At 050 Inch Lift252
    Exhaust Duration At 050 Inch Lift254
    Advertised Exhaust Duration288
    Lifter TypeMechanical Roller
    Duration At 050 Inch Lift252 int./254 exh.
    Valve Springs RequiredYes
    Vendor Part Number12-653-5
    Package Qty1
    Package TypeEA
