Vehicle Info NeededCOMP CAMSPART NUMBER: 249-26028-1
Triple Valve Spring O.D.: 1.686"
$7095
Ships on 09/08/2026
Lowest Price GuaranteeHi-Tech Triple Valve Springs
- Triple Valve Spring
- O.D.: 1.686"
- I.D.: .634"
- Seat Load: 342 lbs/in @ 2.200
- Open Load: 1061 lbs/in @1.200
- Coil Bind: 1.161"
- Rate: 712 lbs/in.
- 1/pkg.
Elite Race™ Triple Valve Springs from COMP Cams® have a 1.000? maximum lift and outside diameter of 1.677?. Designed for use with roller cams and with a 9,000 to 10,000 RPM capacity, they are widely used in Pro Stock and Competition Eliminator, as well as marine and tractor pull applications.The metallurgists at COMP Cams® scrutinize every piece of metal utilized in the creation of Elite Race Valve Springs to make sure they are of unsurpassable quality because fissures within the metal of standard spring wire, caused by molecular contaminants, are the weakest link in valve spring construction. These fissures appear to be immense under the Scanning Electron Microscope but in fact, are just microns wide. Diminishing the occurrence of these fissures in our valve spring steel is the COMP Cams® standard when selecting materials.Valve Springs; Dual Valve Springs; Single Valve Springs; Beehive Springs; Conical Springs; Valve Lift; Max Lift; Spring Kit
Part TypeValve Spring
BrandCOMP CAMS
Package Height2.1
Package Width2.9
Package Length4.3
Weight0.45 PG
Part CategoryPerformance Parts
CoatedNo
Coil Bind Height1.15 in (29.21 mm)
Damper Spring IncludedNo
Spring Rate728 lbs./in.
PositionN/A
Open Height1.2 in (30.5 mm)
Open Pressure (Lbs.)1074
Installed Pressure (Lbs.)346
QuantitySold individually
Installed Height2.2 in (55.88 mm)
Inside Diameter Of Inner Spring0.635 in (16.129 mm)
Valve Spring StyleStandard
Outside Diameter Of Outer Spring1.677 in (42.6 mm)
Inside Diameter Of Outer Spring1.195 in (30.353 mm)
Inside Diameter0.635 in (16.129 mm)
Spring TypeTriple
Spring Rate (Lbs./In.)728
Part FitmentSemi Universal
Outside Diameter1.68 in (42.7 mm)
Number Of Springs Per ValveTriple
Camshaft TypeOEM
Vendor Part Number26028-1
Package Qty1
Package TypeEA
