Vehicle Info NeededCOMP CAMSPART NUMBER: 249-26082-1
Elite Race Triple Valve Spring Seat Load: 382 @ 2.100"
$6595
Ships Tomorrow
Lowest Price GuaranteeElite Race Triple Valve Springs
- Elite Race Triple Valve Spring
- Seat Load: 382 @ 2.100"
- Open Load: 1067 @ 1.200"
- Coil Bind: 1.130"
- Rate: 761 psi
- Outer 1.680" OD, Middle .871" ID, Inner .635" ID
- 1/pkg
- Made From Super Clean Wire
- CNC Machined
- Pre-Set For Initial Load Loss
- 1 Year Limited Warranty
Valve Springs; Dual Valve Springs; Single Valve Springs; Beehive Springs; Conical Springs; Valve Lift; Max Lift; Spring Kit
Part TypeValve Spring
BrandCOMP CAMS
Package Height2.7
Package Width3.1
Package Length4.5
Weight0.45 PG
Part CategoryPerformance Parts
CoatedNo
Coil Bind Height1.13 in (28.702 mm)
Damper Spring IncludedNo
Spring Rate686 lbs./in.
PositionN/A
Open Height1.2 in (30.5 mm)
Open Pressure (Lbs.)949
Installed Pressure (Lbs.)332
QuantitySold individually
Installed Height2.1 in (53.34 mm)
Inside Diameter Of Inner Spring0.635 in (16.129 mm)
Valve Spring StyleStandard
Outside Diameter Of Outer Spring1.645 in (41.8 mm)
Inside Diameter Of Outer Spring1.195 in (30.353 mm)
Inside Diameter0.635 in (16.129 mm)
Spring TypeTriple
Spring Rate (Lbs./In.)686
Outside Diameter1.68 in (42.7 mm)
Number Of Springs Per ValveTriple
Camshaft TypeOEM
Vendor Part Number26082-1
Package Qty1
Package TypeEA
