Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Conical Valve Springs
- Conical Valve Springs
- Rate: 485 lbs
- Inner Diameter: .660'' Top, .990'' Bottom
- Outer Diameter: 1.060'' Top, 1.390'' Bottom
- Seat Load: 160 lbs at 1.900''
- Open Load: 495 lbs at 1.210''
- Coil Bind Height: 1.165''
- 1/pkg
- Reduced Mass Improves RPM Stability
- Conical Design Offers Best Natural Frequency Damping
- Dampens w/o Wear/Heat/Friction Or Risk From Interference Contact
- Progressive Frequency Increases RPM Limit
- Allows For More Aggressive Cams
- Superfinish Surface Processing Increases Max Lift Capability
- Longer Valve Train Component Lift
- Less Parasitic Horsepower Loss
Valve Springs; Dual Valve Springs; Single Valve Springs; Beehive Springs; Conical Springs; Valve Lift; Max Lift; Spring Kit
High-Performance Conical Valve Springs
Comp Cams Conical Valve Springs are designed with a progressive pitch-driven natural frequency that increases valve train RPM limits while reducing resonance concerns and decreasing dynamic spring oscillations. This results in longer spring life and the ability to run a more aggressive camshaft.
Part TypeValve Spring
Product LineComp Cams Conical Valve Springs
BrandCOMP CAMS
Part CategoryPerformance Parts
Coil Bind HeightOEM
Spring TypeSingle
Spring Rate (Lbs./In.)486
Part FitmentSemi Universal
Camshaft TypeN/A
Vendor Part Number7256-1
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
