Vehicle Info NeededCOMP CAMSPART NUMBER: 249-87-131-6
Toyota Magnum Camshaft
$41095
Ships on Sep 04, 2026
Lowest Price GuaranteeToyota 20R and 22R 4 cyl. 1974-1989
- Magnum 280S Mechanical Flat Tappet Camshaft
Lift:.455"/.455"
Duration:283°/283°
Lobe Separation Angle:110°
RPM Range:2000-6000
Best cam for street performance with 5-speed. Good mid-range and top end.
| Operating Range: | 2000-6000 RPM |
| Duration Advertised: | 283° Intake / 283° Exhaust |
| Duration @ .050' Lift: | 242° Intake / 242° Exhaust |
| Valve Lift: | .455' Intake / .455' Exhaust |
| Lobe Separation Angle: | 110° |
Toyota; 20R; 22R
Best cam for street performance with 5-speed. Good mid-range and top end.
Emissions Note:
This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.
CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART
Part TypeCamshaft
BrandCOMP CAMS
Package Height2.9
Package Width3.0
Package Length24.2
Weight6.95 PG
Part CategoryPerformance Parts
Exh. Duration @ .050 In. (Deg)242
Cam StyleMechanical follower
Exh. Duration Advertised (Deg)283
Engine Make/SizeToyota 2.2L
Intake Valve Lift With Factory Rocker Arm Ratio (I0.455
Int. Duration @ .050 In. (Deg)242
Basic Operating Rpm Range2,000-6,000
Intake Valve Lash0.01 in (0.254 mm)
Intake Valve Lift0.455 in (11.557 mm)
Computer-Controlled CompatibleNo
Int. Duration Advertised (Deg)283
Lobe Separation (Deg)110
Rpm Range2000-6000
Advertised Duration283 int./283 exh.
Exhaust Valve Lift With Factory Rocker Arm Ratio (0.455
UsageStreet/Strip
Valve Lift With Factory Rocker Arm Ratio0.455 int./0.455 exh.
QuantitySold individually
Exhaust Valve Lash0.01 in (0.254 mm)
Exhaust Valve Lift0.455 in (11.557 mm)
Advertised Intake Duration283
Intake Duration At 050 Inch Lift242
Exhaust Duration At 050 Inch Lift242
Advertised Exhaust Duration283
Lifter TypeSolid Flat Tappet
Duration At 050 Inch Lift242 int./242 exh.
Valve Springs RequiredYes
Vendor Part Number87-131-6
Package Qty1
Package TypeEA
