Vehicle Info NeededCOMP CAMSPART NUMBER: 249-947-1
Hi-Tech Triple Valve Spring O.D.: 1.645"
$5295
Ships on Sep 03, 2026
Lowest Price GuaranteeHi-Tech Triple Valve Springs
- Hi-Tech Triple Valve Spring
- O.D.: 1.645"
- I.D.: .635"
- Seat Load: 338 lbs/in @ 2.000
- Open Load: 849 lbs/in @1.250
- Coil Bind: 1.145"
- Rate: 681 lbs/in.
- 1/pkg.
- Proprietary Alloy
- Maintain Higher Loads
- 1 Year Limited Warranty
Valve Springs; Dual Valve Springs; Single Valve Springs; Beehive Springs; Conical Springs; Valve Lift; Max Lift; Spring Kit
Engine Valve Spring
Part TypeValve Spring
BrandCOMP CAMS
Package Height1.7
Package Width1.9
Package Length4.0
Weight0.44 PG
Part CategoryPerformance Parts
CoatedNo
Coil Bind Height1.145 in (29.083 mm)
Damper Spring IncludedNo
Spring Rate681 lbs./in.
PositionN/A
Open Height1.25 in (31.8 mm)
Open Pressure (Lbs.)848
Installed Pressure (Lbs.)304
QuantitySold individually
Installed Height2.05 in (52.07 mm)
Inside Diameter Of Inner Spring0.635 in (16.129 mm)
Valve Spring StyleStandard
Outside Diameter Of Outer Spring1.645 in (41.8 mm)
Inside Diameter Of Outer Spring1.195 in (30.353 mm)
Inside Diameter0.635 in (16.129 mm)
Spring TypeTriple
Spring Rate (Lbs./In.)681
Outside Diameter1.645 in (41.8 mm)
Number Of Springs Per ValveTriple
Camshaft TypeHydraulic
Vendor Part Number947-1
Package Qty1
Package TypeEA
