Magnum 270H Hydraulic Flat Tappet Camshaft Complete Kit Lift: .480" /480" Duration: 270°/270° RPM Range: 1800-5800

Name: Magnum 270H Hydraulic Flat Tappet Camshaft Complete Kit Lift: .480" /480" Duration: 270°/270° RPM Range: 1800-5800
Brand: COMP CAMS
SKU: 249-K10-203-4
Price: 660.95 USD
Availability: OutOfStock

Currently Unavailable

This product is no longer available. Please call customer service for assistance at 1-800-345-4545.

American Motors 290-401ci 1966-1991

Lift:

Duration:

RPM Range:

Operating Range:	1800-5800 RPM
Duration Advertised:	270° Intake / 270° Exhaust
Duration @ .050' Lift:	224° Intake / 224° Exhaust
Valve Lift w/1.6 Rockers:	.480' Intake / .480' Exhaust
Lobe Separation Angle:	110°

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART

Part TypeCamshaft Kit

BrandCOMP CAMS

Package Height5.3

Package Width10.5

Package Length25.5

Weight25.8 PG

Part CategoryPerformance Parts

Intake Valve Lift0.48 in (12.192 mm)

Int. Duration Advertised (Deg)270

Rpm Range1800-5800

Lifter TypeHydraulic Flat Tappet
