Comp Cams Marine Mechanical Roller Camshafts

Product Discontinued

COMP CAMSPART NUMBER: 249-K11-702-9

Comp Cams Marine Mechanical Roller Camshafts

Name: Comp Cams Marine Mechanical Roller Camshafts
Brand: COMP CAMS
SKU: 249-K11-702-9
Price: 2009.95 USD
Availability: OutOfStock

Currently Unavailable

This product is no longer available. Please call customer service for assistance at 1-800-345-4545.

Big Block Chevrolet 396-454ci 1965-96

.680"/.680"

306°/319°

110°

4500-7000

Chevelle, Camaro, Corvette, Stingray, Silverado, C10, Firebird, Chevrolet, Big Block, Chevy, BBC, 454, 427, 502, 396, Caprice, Malibu, Impala, Nova, Monte Carlo, S10, 572

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART

Part TypeCamshaft Kit

BrandCOMP CAMS

Package Height5.0

Package Width10.25

Package Length25.5

Weight28.0 PG

Part CategoryPerformance Parts

Exh. Duration @ .050 In. (Deg)282

Cam StyleMechanical roller tappet

Grind Number306AR-10

Exh. Duration Advertised (Deg)319

Locks IncludedYes

Engine Make/SizeChevy Big Block (396-454)

Retainers IncludedYes

Intake Valve Lift With Factory Rocker Arm Ratio (I0.68

Int. Duration @ .050 In. (Deg)271

Assembly Lubricant IncludedNo

Basic Operating Rpm Range4,500-7,000

Pushrods IncludedNo

Gaskets IncludedNo

Intake Valve Lash0.028 in (0.711 mm)

Rocker Arms IncludedNo

Intake Valve Lift0.68 in (17.272 mm)

Computer-Controlled CompatibleNo

Int. Duration Advertised (Deg)306

Lobe Separation (Deg)110

Rpm Range4500-7000

Lifter StyleMechanical roller

Advertised Duration306 int./319 exh.

Exhaust Valve Lift With Factory Rocker Arm Ratio (0.68

Valve Springs IncludedYes

UsageMarine

Valve Lift With Factory Rocker Arm Ratio0.680 int./0.680 exh.

Camshaft Gear Attachment3-bolt

QuantitySold as a kit

Valve Stem Seals IncludedYes

Exhaust Valve Lash0.03 in (0.762 mm)

Exhaust Valve Lift0.68 in (17.272 mm)

Advertised Intake Duration306

Outside Diameter Of Outer Spring1.57 in (39.9 mm)

Intake Duration At 050 Inch Lift270

Exhaust Duration At 050 Inch Lift280

Timing Chain StyleDouble roller

Timing Chain And Gears IncludedYes

Advertised Exhaust Duration319

Lifter TypeMechanical Roller

Part FitmentSemi Universal

Duration At 050 Inch Lift270 int./280 exh.

Valve Springs RequiredNo

Lifters IncludedYes

Vendor Part NumberK11-702-9

Package Qty1

Package TypeEA
