Vehicle Info NeededCOMP CAMSPART NUMBER: 249-K12-268-4
Xtreme Energy 268H Hydraulic Flat Tappet Camshaft Complete Kit Lift: .477"/.480" Duration: 268°/280° RPM Range: 1800-5800
$65595
3 left in stock
Ships Tomorrow
Lowest Price GuaranteeChevy 262-400ci Small Block 1987-98 Computer Controller
- Xtreme Energy 268H Hydraulic Flat Tappet Camshaft Complete Kit
Lift: .477"/.480''
Duration: 268°/280°
RPM Range: 1800-5800
Best Cam For Modified 350 TPI with Improved Chip, Injectors, Plenum, Runners & Exhaust
| Operating Range: | 1800-5800 RPM |
| Duration Advertised: | 268° Intake / 280° Exhaust |
| Duration @ .050' Lift: | 224° Intake / 230° Exhaust |
| Valve Lift: | .477' Intake / .480' Exhaust |
| Lobe Separation Angle: | 114° |
265, 283, 307, 302, 305, 327, 350, 383, 400, 427, L46, L48, L65, LM1, LT-1, L82, L81, LS9, L83, L98, L05, LG3, LG4, LT1, LT4, Camaro, Corvette, Chevelle, Stingray, Silverado, C10, Firebird, Chevrolet, Chevy, Small Block Chevy, Caprice, Malibu, Impala, Nova, 355, GEN1, Monte Carlo, S10
Best cam for modified 350 TPI with improved chip, injectors, plenum, runners and exhaust.
Emissions Note:
This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.
CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART
Part TypeCamshaft Kit
BrandCOMP CAMS
Package Height5.2
Package Width10.4
Package Length25.3
Weight21.2 PG
Part CategoryPerformance Parts
Exh. Duration @ .050 In. (Deg)230
Cam StyleHydraulic flat tappet
Grind NumberCS XE268H-14
Exh. Duration Advertised (Deg)280
Locks IncludedYes
Engine Make/SizeChevy Small Block (262-400)
Retainers IncludedYes
Intake Valve Lift With Factory Rocker Arm Ratio (I0.479
Int. Duration @ .050 In. (Deg)224
Assembly Lubricant IncludedYes
Basic Operating Rpm Range1,800-5,800
Pushrods IncludedNo
Gaskets IncludedNo
Rocker Arms IncludedNo
Intake Valve Lift0.479 in (12.167 mm)
Computer-Controlled CompatibleYes
Int. Duration Advertised (Deg)268
Lobe Separation (Deg)114
Rpm Range1800-5800
Lifter StyleHydraulic flat tappet
Advertised Duration268 int./280 exh.
Exhaust Valve Lift With Factory Rocker Arm Ratio (0.48
Valve Springs IncludedYes
UsageStreet/Performance
Valve Lift With Factory Rocker Arm Ratio0.479 int./0.480 exh.
QuantitySold as a kit
Valve Stem Seals IncludedYes
Exhaust Valve Lift0.48 in (12.192 mm)
Advertised Intake Duration268
Outside Diameter Of Outer Spring1.254 in (31.9 mm)
Intake Duration At 050 Inch Lift224
Exhaust Duration At 050 Inch Lift230
Timing Chain StyleDouble non-roller
Timing Chain And Gears IncludedYes
Advertised Exhaust Duration280
Lifter TypeHydraulic Flat Tappet
Part FitmentSemi Universal
Duration At 050 Inch Lift224 int./230 exh.
Valve Springs RequiredNo
Lifters IncludedYes
Vendor Part NumberK12-268-4
Package Qty1
Package TypeEA
