Eastwood 21560 Features:

The Eastwood Press Brake Attachment is a precision engineered metal working tool designed to produce accurate, variable length bends in angles up to 90° in mild steel and aluminum in widths up to 12 and thicknesses up to 3/8. Create complex shapes Bends up to 90° angles Attaches to Most Standard 12 or 20 Ton Hydraulic Shop Presses Create complex shapes such as floor reinforcement channels and ribs, sections of corrugated pickup bed floors; truck bedside panels, inner fender structures, suspension brackets, engine/transmission mounts and much more all with one convenient accessory tool.

• Attach to most standard 12 or 20 ton hydraulic shop presses
• Upper die mounting cup inside diameter: 41mm
• Bending length max: 12"
• Overall dimensions: 14.5" wide x 7.5" deep x 9.25" high
• Bottom die overall width: 2.25 in
• Bottom die overall height: 1.75 in
• Bending thickness (varies according to metal hardness and width of work piece)
• Examples for mild steel:
• 3/16" x 12" width
• 5/16" x 6" width
• 3/8" x 3" width
