Product Discontinued
EDELBROCKPART NUMBER: 350-5777
Sure Seat Valve Springs for 1957-1989 Small Block Chrysler 318-360 OE Cast Iron Head Non-Rotator
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Small Block Chrysler
- Sure Seat Valve Springs
- 1957-1989 Small Block Chrysler 318-360
- Outside Diameter: 1.494"
- Inside Diameter: 1.080"
- Seat Pressure: 96 lbs
- Installed Height: 1.650"
- Coil Bind: 1.100"
- Cast Iron OE Heads
- Non-Rotator
- For Use With Original Equipment Cast Iron Heads Only
- Designed for use with 350-7177 RPM Cam
- Open Pressure: 238 lbs @ .430"
Part TypeValve Spring
BrandEDELBROCK
Package Height2.3
Package Width3.6
Package Length12.5
Weight3.85 PG
Part CategoryPerformance Parts
CoatedNo
Coil Bind HeightOEM
Damper Spring IncludedYes
PositionExhaust Or Intake
Open Height1.65 in (41.9 mm)
Open Pressure (Lbs.)238
Installed Pressure (Lbs.)96
QuantitySold as a set of 16
Installed Height1.65 in (41.91 mm)
Inside Diameter Of Inner Spring1.075 in (27.305 mm)
Valve Spring StyleStandard
Outside Diameter Of Outer Spring1.5 in (38.1 mm)
Inside Diameter Of Outer Spring1.075 in (27.305 mm)
Inside Diameter1.075 in (27.305 mm)
Spring TypeSingle
Spring Rate (Lbs./In.)N/A
Part FitmentSemi Universal
Outside Diameter1.5 in (38.1 mm)
Number Of Springs Per ValveSingle
Camshaft TypeMechanical
Vendor Part Number5777
Package Qty1
Package TypeEA
