Vehicle Info NeededEDELBROCKPART NUMBER: 350-5895
Complete Sure Seat Valve Spring Kit for Big Block Chevy 396-454 OE Cast Iron Head
$28095
4 left in stock
Ships Today
Lowest Price GuaranteeBig Block Chevy
- Sure Seat Valve Spring Kit
- Big Block Chevy 396-454
- Outside Diameter: 1.500"
- Inside Diameter: 1.082"
- Coil Bind: 1.340"
- Cast Iron OE Heads
- Non-Rotator
- Includes spring, retainer & stem locks
- Complete Kit: Includes Retainers And 7° Locks
- For Use With Original Equipment Cast Iron Heads Only
- Designed for use with 350-2162 Performer Cam
- Open Pressure: 220 lbs @ .420"
- Seat Pressure: 90 lbs
- Installed Height: 1.880"
Part TypeValve Spring
BrandEDELBROCK
Package Height2.6
Package Width3.6
Package Length12.6
Weight5.89 PG
Part CategoryPerformance Parts
CoatedNo
Installed Pressure (Lbs.)90
Locks IncludedYes
Installed Height1.88 in (47.752 mm)
Inside Diameter Of Inner Spring1.082 in (27.483 mm)
Retainers IncludedYes
Lock Style7 degree
Inside Diameter1.082 in (27.483 mm)
Spring TypeSingle
Number Of Springs Per ValveSingle
Camshaft TypeHydraulic
Coil Bind Height1.34 in (34.036 mm)
Damper Spring IncludedYes
PositionN/A
Open Height1.88 in (47.8 mm)
Lock Groove Quantity1-groove
Open Pressure (Lbs.)220
QuantitySold as a kit
Valve Spring StyleStandard
Outside Diameter Of Outer Spring1.5 in (38.1 mm)
Inside Diameter Of Outer Spring1.082 in (27.483 mm)
Lock MaterialSteel
Spring Rate (Lbs./In.)N/A
Part FitmentSemi Universal
Outside Diameter1.5 in (38.1 mm)
Retainer MaterialSteel
Vendor Part Number5895
Package Qty1
Package TypeEA
