Made in USA
Pro-Port Raw Big Victor 3 Cylinder Head for Big Block Chevy
Product Discontinued
EDELBROCKPART NUMBER: 350-614669

Pro-Port Raw Big Victor 3 Cylinder Head for Big Block Chevy

Currently Unavailable

This product is no longer available. Please call customer service for assistance at 1-800-345-4545.

Big Victor 3 Pro-Port Cylinder Heads
    Big Victor 3 Pro-Port Cylinder Head
  • Big Block Chevy
  • Semi-Finished
  • 38cc Combustion Chamber
  • HIP Process
  • Valve Size: 2.52"/1.90"
  • Sold Individually



    Exhaust Port Exit:1.84"x 1.50"
    Valve Sizes:2.52' Intake / 1.90' Exhaust (These are the maximum allowable size for each valve; these maximum sizes may not be used together)
    Valve Pierce Points (X, Y):0.690', 0.545' Intake
    -1.270',0.350' Exhaust
    Coordinates provided are cylinders 1, 3, 6, 8.
    Invert 'X' value for cylinders 2, 4, 5, 7.
    Valve Spacing:--
    Valve Guides:Included
    Valve Seats:--
    Valve Angle:11°
    HIP Processed:Yes

    Emissions Note:

    This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

    CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART

    Since founder Vic Edelbrock Sr. began building performance intake manifolds in 1938, Edelbrock has grown into one of the most trusted names in American high-performance parts, from carburetors and intake manifolds to cylinder heads, crate engines, and EFI systems. JEGS has spent decades supplying Edelbrock components to racers, engine builders, and street enthusiasts, backing this extensive lineup with in-house technical support, fast shipping, and a Price Match Guarantee so you can choose proven Edelbrock parts with confidence.

    Victor Pro-Port Raw Big Block Chevy Cylinder Heads for Professional Head Porters

    Edelbrock has designed the perfect head for a professional cylinder head porter and engine builder. These heads are unported versions of Edelbrock's race-winning Victor series heads. The Victor Pro-Port cylinder heads are a semi-finished casting that gives the professional cylinder head porter the ideal starting point to design their own hand or CNC port. To allow for custom porting, the ports and chambers are un-machined and manganese-bronze valve guides and valve seats are available with certain heads. The Pro-Port heads are cast right here in the USA at Edelbrock's state-of-the-art facility.

    Show More

    NOTE: These heads can not be used without professional head preparation.

    HIP Process HIGH-TECH PROCESS DELIVERS STRONGER CASTINGS
    Heads are available with a technique called Hot Isostatic Pressing (HIP). This aerospace process takes raw castings up to 900° F in a pressurized chamber (up to 30,000 psi) and compresses the casting. The results: an incredibly strong, super dense sand casting that has three times the fatigue life and nearly the consistency of billet aluminum.

Part TypeCylinder Head
Product LineEdelbrock Big Block Chevy Victor Pro-Port Cylinder Heads
BrandEDELBROCK
Package Height9.0
Package Width12.12
Package Length26.5
Weight70.0 PG
Part CategoryPerformance Parts
UsageRacing
TypeBare
PreparationRequires Professional Preparation (Bare)
EmissionNon-Emissions
Cylinder Head TypeBig Duke
Part FitmentSemi Universal
FinishSemi-finished
Engine Make/SizeChevy Big Block (540-632)
Vendor Part Number614669
Package Qty1
Package TypeEA
