Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Victor Jr. LS
- Victor Jr. LS3_LSX Pro-Port Raw Cylinder Head
- Rectangle Port
- Intake Port Entry: 1.00" x 2.37"
- Exhaust Port Exit: 1.38" x 1.00"
- Valve Size: 2.165" Intake/1.60" Exhaust
- LSx Block
- Sold Each
Don't get bogged down by the limitations of porting stock GM heads. No more extremely larg eport and thin walled cylinder heads. These Pro-Port Victor Jr. LS3-LSX heads are designed with undersized ports and omitted combustion chambers to give head porters more flexibility in port design while retaining a more robust architecture. All machining except the exhaust flange and spring pockets, matches stock GM LS3/L76/L92 cylinder heads. This includes valve location and angle, Intake flange, and accessory bolts on the ends of the heads. Valve seats and valve guides are included.
Combustion Chamber Size: (Unfinished Size) Intake Port Entry: 1.00" x 2.37" Exhaust Port Exit: 1.38"x 1.00' Valve Sizes: 2.165' Intake / 1.60' Exhaust Valve Pierce Points (X, Y): 0.854', 0.017' Intake
-1.156', 0.017' Exhaust
Coordinates provided are cylinders 1, 3, 6, 8.Valve Spacing: 2.010" Valve Guides: Included Valve Seats: Included Valve Angle: 15° HIP Processed: No
)
Part TypeCylinder Head
BrandEDELBROCK
Package Height8.38
Package Width10.88
Package Length26.0
Weight31.0 PG
Part CategoryPerformance Parts
UsageCompetition
TypeBare
PreparationRequires Professional Preparation (Bare)
EmissionNon-Emissions
Cylinder Head TypeStandard
FinishCast Aluminum
Engine Make/SizeChevy Victor JR. LS3/LSX
Vendor Part Number77349
Package Qty1
Package TypeEA
