Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
E-CNC 355 Cylinder Head110cc Combustion Chambers
- Big Block Chevy 396-502ci
- Intake Ports 348cc (LH) 356cc (RH)
- Exhaust Ports 145cc
- 110cc Combustion Chamber
- 7/16" Rocker Studs
- Bare Head, Sold Individually
Combustion Chamber Volume: 110cc Intake Runner Volume: 348cc (LH) / 356cc (RH) Exhaust Runner Volume: 145cc Intake Valve Diameter: 2.30' (valves not included) Exhaust Valve Diameter: 1.88' (Valves not included) Valve Stem Diameter: 11/32' (Valves not included) Valve Guides: Manganese Bronze Deck Thickness: 5/8' Valve Spring Diameter: N/A Valve Spring Maximum Lift: N/A Rocker Stud: N/A Guideplate: N/A Pushrod Diameter: N/A Valve Angle: 24.5° x 4.4° (Intake) / 15.5° x 4.2° (Exhaust) Exhaust Port Location: Stock Spark Plug Fitment: 14mm x 3/4' Reach,
Gasket SeatValve Lift Intake Exhaust .200' 155 129 .300' 235 181 .400' 292 214 .500' 330 241 .600' 354 252 .700' 368 257 Flow Numbers as tested by Edelbrock's SuperFlo SF-1020 flow bench @ 28' H2O
Part TypeCylinder Head
BrandEDELBROCK
Package Height8.5
Package Width11.0
Package Length24.75
Weight44.0 PG
Part CategoryPerformance Parts
Vendor Part Number79529
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
