Victor Series Circle Track Aluminum Water Pump 1955-1995 Small Block Chevy
InfoVehicle Info Needed
EDELBROCKPART NUMBER: 350-8816

Victor Series Circle Track Aluminum Water Pump 1955-1995 Small Block Chevy

$37995
ShippingShips on Sep 04, 2026
Lowest PriceLowest Price Guarantee

Chevy
    Victor Series Circle Track Aluminum Water Pump
  • 1955-1995 Small Block Chevy
  • -08AN auxiliary fittings at 90° to the block
  • Hard Black Anodized Finish

    Fits all 1955-1995 Small Block Chevy engines. Comes with heavy-duty 3/4" ball/roller bearing.
  • Dimension from block surface to hub: 5-13/16"
  • Inlet Diameter: 1.85"
  • Pilot Shaft: 3/4"

    Since founder Vic Edelbrock Sr. began building performance intake manifolds in 1938, Edelbrock has grown into one of the most trusted names in American high-performance parts, from carburetors and intake manifolds to cylinder heads, crate engines, and EFI systems. JEGS has spent decades supplying Edelbrock components to racers, engine builders, and street enthusiasts, backing this extensive lineup with in-house technical support, fast shipping, and a Price Match Guarantee so you can choose proven Edelbrock parts with confidence.

    These competition water pumps are designed for circle track and endurance racing applications. They feature a revised impeller entry, a black anodized finish and .100" thicker rear cover for greater durability. The water pump housing is equipped with auxiliary AN or NPT water outlets to ease fabrication of custom plumbing systems. These water pumps provide maximum cooling with equal (+/- 1%) distribution to both sides of the block. By eliminating hot spots, the engine produces optimum power from every cylinder without detonation and pre-ignition. Other features include billet hub and heavy-duty ball/roller bearings.

    Show More
    Circle Track Water Pump Dyno Tests
    Dyno Tests show that Edelbrock Pumps deliver substantial flow as well as distributing water almost equally to both sides of the engine.
    SMALL-BLOCK CHEVY CIRCLE TRACK PUMP p/n 350-8816
    Pump RPMLeft Flow
    (gal/min)
    Right Flow
    (gal/min)
    200014.3714.84
    300021.9522.40
    400029.5229.82
    500037.0836.70
    SMALL-BLOCK FORD CIRCLE TRACK PUMP p/n 350-8833
    Pump RPMLeft Flow
    (gal/min)
    Right Flow
    (gal/min)
    200016.0316.16
    300024.0724.11
    400032.3132.51
    500040.1240.08
Part TypeWater Pump
Product LineEdelbrock Victor Series Circle Track Water Pumps
BrandEDELBROCK
Package Height8.6
Package Width9.1
Package Length13.8
Weight9.7 PG
Part CategoryPerformance Parts
Pump MaterialAluminum
Pilot Diameter0.75 in (19.1 mm)
QuantitySold individually
Water Pump RotationClockwise
Engine Make/SizeChevy Small Block (262-400)
Pump FinishBlack anodized
Pump FlowHigh-volume
TypeMechanical
Water Pump Inlet Diameter1.84 in (46.7 mm)
StyleCompetition
Part FitmentSemi Universal
FinishBlack
Vendor Part Number8816
Package Qty1
Package TypeEA
