Tremec 6-Speed 700 ft/lbs Torque Capacity Gear Ratios:

Name: Tremec 6-Speed 700 ft/lbs Torque Capacity Gear Ratios:
Brand: FORD PERFORMANCE
SKU: 397-M-7003-M6295
Price: 3545.00 USD
Availability: OutOfStock

Currently Unavailable

This product is no longer available. Please call customer service for assistance at 1-800-345-4545.

6-Speed Transmissions

700 ft/lbs Torque Capacity
Gear Ratios:
1st: 2.97
2nd: 2.10
3rd: 1.46
4th: 1.00
5th: 0.74
6th: 0.50

Fits:
289-351W
4.6L SOHC/DOHC Can be used in 1999-2004 Mustangs and Cobras
5.0L Ti-VCT engines
Notes:
For SBF 302/351 use Quicktime bellhousing part # 8031
For modular 4.6L/5.0L/5.4L use Quicktime bellhousing part # 8080
May require shorter driveshaft, modified crossmember/trans mount and other minor modifications
Specs:
Gear ratios: 1st 2.97; 2nd 2.10; 3rd 1.46; 4th 1.00; 5th 0.74; 6th 0.50
26-spline input shaft; 31-spline output shaft
Provision for both mechanical and electronic speedometer
Mechanical speedo drive gear has 7 teeth
Electronic speedo rotor has 12 positions
These are the same Tremec HD 5-speed manual transmissions used in the 1995 Mustang Cobra "R" models with the 351 5.8L engines.
4615 Steel Gears
Billet Aluminum Shifter

Built to handle the torque of today's modified engines, these high-performance transmissions are available in a 5-speed or 6-speed version. Sometimes stock just isn't enough to hold the torque or your driving style. With some additional parts and minor modifications, you can double a transmission's torque capacity without resorting to an unfriendly street solution. Don't get worked over by your transmission, get the transmission Ford would have used if they built your car.

Features:
