Engine Swap Wiring Harness for 2009-2014 GM Gen IV LS3 6.2L & L92 6.2L Truck Engines w/T56, TR6060 Manual Transmission [DBW]

Name: Engine Swap Wiring Harness for 2009-2014 GM Gen IV LS3 6.2L & L92 6.2L Truck Engines w/T56, TR6060 Manual Transmission [DBW]
Brand: JEGS
SKU: 555-10426
Price: 435.99 USD
Availability: InStock

^$435⁹⁹$436.99You Save$1.00

4 left in stock

Ships Tomorrow

Lowest Price Guarantee

GM Gen IV LS 6.2L with Drive-by-Wire

Engine Swap Wiring Harness

2009-2014 GM Gen IV LS3 6.2L & L92 6.2L Truck Engines

T56/TR6060 Manual or Non-Electronic Automatic Transmissions

Drive-by-Wire (DBW)

Stand Alone Wiring Harness

58x Crank Sensor

EV6 Injector

Sold as a Kit

JEGS 555-10426 GM Gen IV LS3 6.2L & L92 6.2L Truck Engine Swap Wiring Harness Includes:

Fuse/Relay Box
Fuel Pump Control Connection
Fan Control Connections, 2 Wires
Check Engine Light Connection
Vehicle Speed Sensor Connection, 2-Pin
Tachometer Connection
OBD2 Port Connection
Accelerator Pedal Drive-by-Wire (DBW), 6-Pin
Throttle Body Connection, 6-Pin
MAF Sensor Connection, 5-Pin
MAP Sensor Connection, 3-Pin
Engine Coolant Temp Sensor Connection, 2-Pin
Alternator Control Connection, 2 Wires
(2) Upstream Oxygen Sensor Connections
58x Crankshaft Position Sensor Connection, 3-Pin
Camshaft Position Sensor Connection, 5-Pin
EV6 Fuel Injector Connections, 2-Pin
Coil Pack Connections, 7-Pin
Ignition Switch Output, 1 Wire
Engine Grounds, 2 Eyelets
Battery Power, 2 Eyelets
ISS (Input Shaft Speed) Connection, 2-Pin
Knock Sensor Connection, 2-Pin
E85 Sensor Connection, 1 Wire

JEGS 555-10426 GM Gen IV LS3 6.2L & L92 6.2L Truck Engine Swap Wiring Harness Features:

Designed for 2009-2014 GM Gen IV LS3 6.2L & L92 6.2L Truck Engines and T56/TR6060 Manual or Non-Electronic Auto
New GM-style fuel injector harness designed to work with OE EV6-style connectors
OE Style OBDII connector and mounting bracket
Compatible with all OE GM sensors
Includes fuse block

JEGS 555-10426 GM Gen IV LS3 6.2L & L92 6.2L Truck Engine Swap Wiring Harness Note:

It is very important to fully read the enclosed instruction manual before installing this wiring harness to ensure a successful installation

Additional Component Part Numbers Not Included

Main Computer, Powertrain Control Module (PCM) GM# 9354896, 12200411
Manifold Absolute Pressure (MAP) Sensor GM# 16212460, Delco# 12614970
Ignition Coil GM# 12558948
Oxygen Sensor (02) GM# 25161131, Delco# AFS123
Mass Air Flow Sensor (MAF) GM# 125168491, Delco# 213-364
Throttle Position Sensor (TPS) GM# 17123852, Delco# 213-912
Cam Position Sensor GM# 12561211, Delco# 213-363
Crankshaft Position Sensor GM# 12560228, Delco# 213-354
Accelerator Pedal GM# 25835421 (CORVETTE) GM# 10379038 (CTS-V)
Knock Sensor GM# 10456603

Simple Wiring for your GM LS/LT Series Engine

Swapping an LS or LT series engine into your classic truck or muscle car is an inexpensive way to breathe new life into your ride. Every transplant presents its challenges, most come in the form of wiring. Why spend hours tracking down broken wires and connectors when you can simplify the entire process with a JEGS stand-alone engine and transmission wiring harness. Each harness utilizes OE GM sensors, and the pre-labeled wiring makes installation as easy as... ready, set, go!

Part TypeWiring Harness

Product LineJEGS LS/LT Stand Alone Wiring Harnesses

BrandJEGS

Package Height4.5

Package Width11.8

Package Length19.0

Weight6.37 PG

Part CategoryPerformance Parts

Efi System ManufacturerStock

Metering StyleMass airflow

Injector Plug StyleUSCAR

QuantitySold individually
