JEGS 555-93750 Factory Assembly Manual for 1966 Chevrolet Corvette

This high-quality reprint of the 1966 Corvette Assembly Instruction Manual provides detailed assembly illustrations, including exploded views of nearly every part, down to the last nut and bolt. It includes part group numbers and helps with disassembly, reassembly, and part identification. Covering both standard models and factory options, this guide includes production details on body assembly, mounting, frame, suspension, brakes, engine, transmission, fuel and exhaust systems, steering, wheels and tires, sheet metal, electrical components, radiator and grille, bumpers, and more. Additionally, it includes options such as the radio, speakers, heater, and power windows. Packed with exploded views, wiring diagrams, torque specifications, and handwritten factory revision notes, this manual offers valuable insight into factory assembly. As with all assembly manuals, this is a reproduction of an internal factory document, meaning some print quality may be light due to original formatting. This unbound manual is the best available reproduction and a must-have resource for anyone restoring or working on a 1966 Corvette.

JEGS 555-93750 Factory Assembly Manual for Detailed Repair and Assembly Procedures Included:

• General Information
• UPC 1 Body
• UPC 2 Frame
• UPC 3 Front Suspension
• UPC 4 Rear Suspension
• UPC 5 Brakes
• UPC 6 Engines
• UPC 7 Transmissions
• UPC 8 Fuel Line Exhaust
• UPC 9 Steering
• UPC 10 Tires and Wheels
• UPC 11 Chassis Sheet Metal
• UPC 12 Electrical
• UPC 13 Radiator and Radiator Grille
• UPC 14 Bumpers & Miscellaneous
