Vehicle Info NeededMELLINGPART NUMBER: 689-466574
466574 Intake Valve Spring for Ford 7.3L Godzilla Engine
$1099
Ships on 09/04/2026
Lowest Price GuaranteeSprings by Application
Beehive Intake Valve SpringInstalled Load/Height: 80 lbs. @ 2.632 in. Open Load/Height: 346 lbs. @ 1.662 in. O.D. 1.245 in. I.D. 0.695 in. Coil Bind: 1.606 in. Chrome Silicone Sold Individually
Valve Spring Installation Notes
Melling 466574 Performance Intake Valve Spring Technical Specifications:
- Dimensions are compatible with the Ford 7.3L Godzilla engine
- Closed Pressure: 80 PSI
- Coil Bind Height: 1.606 in. (41 mm)
- Inside Diameter: 0.695 in. (18 mm)
- Installed Height: 2.362 in. (60 mm)
- Installed Pressure: 80 PSI
- Open Pressure: 346 PSI
- Outside Diameter: 1.245 in. (32 mm)
- Spring Closed Height: 2.362 in. (60 mm)
- Spring Open Height: 1.662 in. (42 mm)
- Spring Type: Performance Beehive Spring
- Material: Chrome Silicone
Valve Springs for Performance Camshafts
Melling Performance Valve Springs are available for engines with performance cams from mild street to all-out-race. Get the most out of your camshaft with the correct valve springs.
Part TypeValve Spring
Product LineMelling Performance Valve Springs
BrandMELLING
Part CategoryPerformance Parts
Coil Bind Height1.614 in.
Inside Diameter0.695 in.
Installed Pressure80 psi
Spring TypeSingle Spring
MaterialChrome Silicon
Outside Diameter1.245 in.
Installed Height2.362 in.
Open Pressure346 psi
Spring Open Height1.662 in.
Grade TypePerformance
Vendor Part Number466574
Package Qty1
Package TypeEA
