Vehicle Info NeededMILE MARKERPART NUMBER: 694-76-50115BW
PE4500 Element Sealed Winch Mounting Plate & Strap
$59900
Ships Tomorrow
Lowest Price Guarantee- PE4500 Element Sealed Winch
- Mounting Plate & Strap
- Waterproof
- 4500lb rated pull line
- Rugged planetary gear sets
- Gear Ratio: 294:1
- 1.9HP permanent magnet motor
- Power-in/power-out remote control
- Dimensions: 17.2" x 6.2" x 7.3"
The Mile Marker ATV & Utilty Winch with mounting plate & strap has a 4500lb rated pull line to go with a 1.9HP permanent magnet motor. Includes "power-in", "power-out"remote control, 1/4" x 80' cable, integrated kill switch, roller fairlead, and rugged planetary gear sets. Redesigned solenoid for longer duty cycle. Includes winch mount plate & strap. Dimensions are 17.2"L x 6.2"W x 7.3"H and weighs 51 lbs.
Show More
Features:
- 4500lb rated pull line
- 1.9HP permanent magnet motor
- Power-in/power-out remote control
- 1/4" x 80' galvanized aircraft cable
- Galvanized roller fairlead
- Integrated kill switch
- Rugged planetary gear sets
- Gear Train: 3-Stage Planetary
- Gear Ratio: 294:1
- Motor: Permanent Magnet, 1.9 hp (1.4kw), 12 V
- Control Pendant: Illuminated Joystick Remote, 12'
- Dimensions (LxWxH): 17.2" x 6.2" x 7.3"
- Cable: 1/4" x 80' (nominal 7000 lbs, 3175 kg)
- Drum Size: 2.5" x 5.5"
- Net weight 51 lbs
- Bolt Pattern: 4 Bolts, 6.535" x 4.5"
Part TypeWinch
Product LineMile Marker ATV/UTV Tough Series 4500lb Winch
BrandMILE MARKER
Package Height8.5
Package Width14.5
Package Length25.0
Weight83.9 PG
Part CategoryReplacement Parts
TypeATV
Voltage12 DC
Rated Single Line Pull (Lbs.)4500
Part FitmentUniversal
Vendor Part Number76-50115BW
Package Qty1
Package TypeEA
Some parts are not legal for use in California or other states with similar laws / regulations
