Vehicle Info NeededMOROSOPART NUMBER: 710-20616
20616 Drag Race Oil Tube Chassis Super and Bracket Classes
$78199
2 left in stock
Ships Tomorrow
Lowest Price GuaranteeFord
- Drag Race Oil
- Tube Chassis Super and Bracket Classes
- Ford 429-460
- Deep Sump
- Rear Wet Sump
- 9-Quart Capacity
- 7.875" Depth
- Black Steel
Recommended Pickup: - 710-24505 Fits Ford Motorsports 397-M-6600-A460 and Mellings 689-M84D or 689-M84DHV pumps (with 4-bolt main block)
- 710-24522 Fits Ford Motorsports 397-M-6600-A460 and Mellings 689-M84D or 689-M84DHV pumps (with 2-bolt main block)Features:
- Fits tube chassis Bracket and Super Classes including dragsters, roadsters and door slammers
- Fully fabricated steel pan
- Utilizes "Race" pan rail bolt pattern
- Accepts 4.75" stroke with aluminum rods
- Clears all 4-bolt main caps
- Power Kick-outs for increased horsepower
- Increased sump capacity reduces engine temperature
- Solid louvered aluminum windage tray
- Compatible with Tilton-style starter and 184-tooth flywheelNotes: Oil pan capacities do not include oil filter capacity
Part TypeOil Pan
BrandMOROSO
Package Height7.25
Package Width9.12
Package Length24.62
Weight21.24 PG
Part CategoryPerformance Parts
Oil Pan Capacity9 quarts
Hardware IncludedNo
Dipstick ProvisionNo
BaffledYes
Sump StyleWet
Pickup IncludedNo
Drain Plug Thread Size (In.)1/2-20
QuantitySold individually
Oil Pan FinishBlack
Kickout PositionDriver and passenger side
Oil Pan MaterialSteel
Maximum Stroke With Oe Rod4.75 in (120.65 mm)
Gaskets IncludedNo
Oil Pan Depth8 in (203.2 mm)
Sump LocationFull
Crank Scraper IncludedYes
Windage Tray IncludedYes
Part FitmentSemi Universal
Kicked OutYes
Stroker ClearancedYes
Vendor Part Number20616
Package Qty1
Package TypeEA
