Made in USA
Street-Q Series Carburetor 850 CFM
InfoVehicle Info Needed
QUICK FUELPART NUMBER: 793-SQ-850

Street-Q Series Carburetor 850 CFM

$87095
1 left in stock
ShippingShips Today
Lowest PriceLowest Price Guarantee

    Street-Q Series Carburetor
  • 850 CFM
  • With QuickLink Mechanical Secondary Adjustment

    Specifications:

  • Throttle Bore: 1-3/4"
  • Primary Jet: 22-76
  • Secondary Jet: 22-84
  • Idle Bleed: 26-70
  • Hi-Speed Bleed: 26-33
  • Pump Nozzle: 26-33
  • Power Valve: 25-45
  • Needle & Seat: 18-3
  • Fuel Type: Gas

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART

Quick Fuel Street-Q Series Carburetors are designed for street/strip use and will provide you with unmatched performance, at a reduced price. The difference between Street-Q and Race-Q series carburetors is the use of die-cast aluminum metering blocks and throttle body, rather than fully-machined billet aluminum components. All of the critical functionality is retained, including two-circuit metering, downleg boosters, and a four-corner idle system. Street-Q carburetors are available in both mechanical and vacuum secondary adjustment models.

Show More

Features:

    • Designed for Street/Strip Applications
    • Die-cast Aluminum Components
    • Dual Metering Blocks
    • Mechanical and Vacuum Secondary Models Available
    • Changeable Air Bleeds
    • Throttle Lever With Universal Design

JEGS Easy Kits are designed by JEGS high performance racing professionals to help you get all the performance parts you need for your race car, hot rod or truck.

Part TypeCarburetor
Product LineQuick Fuel Street-Q Series Carburetors
BrandQUICK FUEL
Package Height7.9
Package Width11.2
Package Length12.3
Weight9.05 PG
Part CategoryPerformance Parts
Primary Discharge Nozzle Size0.033 in (0.8 mm)
Secondary Discharge Nozzle Size0.033 in (0.8 mm)
Carburetor FinishPolished
Part FitmentSemi Universal
Vendor Part NumberSQ-850
Package Qty1
Package TypeEA
