Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Super T-10 Plus 2-Speed Transmissions
- Super T-10 Plus 2-Speed Transmission
- GM Applications
- 1st Gear Ratio: 1.12:1
- 2nd Gear Ratio: 1.00:1
- Input Shaft: 1-1/8" 26-Spline
- Output Shaft: 1-3/8" 32-Spline
- Synchronized In All Forward Gears
- First/Reverse In Constant Mesh
- Strut Type Synchros For Long Life/Easy Shifting
- Built For Performance Cars/Light Trucks
- Sanctioned By Many Racing Series
- Straight Cut Gears/Legal OEM Case
- Interchangeable Cluster
- Made In The USA
- In a variety of ratios, the Richmond Super T-10 Plus 2-Speed is designed for dirt or asphalt racing where rules require an OE transmission with external clutch. This 2-speed has only two forward gears and reverse, which equals less rotating weight for more horsepower.
Part TypeManual Transmission
Product LineRichmond 2-Speed Transmissions
BrandRICHMOND GEAR
Package Height16.5
Package Width17.0
Package Length35.0
Weight74.0 PG
Part CategoryPerformance Parts
Yoke IncludedNo
Number Of GearsTwo
Second Gear Ratio1.00:1
Trans YearOEM
QuantitySold individually
Yoke StyleSlip On
Output Shaft Spline Diameter1.375 in (34.9 mm)
Shifter Style RequiredLong
Tailshaft Length12 in (304.8 mm)
First Gear Ratio1.12:1
Input Spline Quantity26 in (660.4 mm)
Trans ModelBorg- Warner Super T- 10 (Man)4 Speed
Input Shaft Diameter1.125 in (28.575 mm)
Shifter IncludedNo
Case MaterialAluminum
Output Shaft Spline Quantity32
Bellhousing IncludedNo
Vendor Part Number7020026B
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
