Product Discontinued
Currently Unavailable
This product is no longer available. Please call customer service for assistance at 1-800-345-4545.
Vacuum Schematic Manuals
Vacuum Schematic Manual1969 Ford Mustang
Scott Drake MP-152 Features:
Saves time and frustration! Shows schematic and diagrams that reveal the location and function of the many vacuum systems on Mustangs and ShelbysFactory Information to Guide You Through Your Restoration
Scott Drake Service and Repair Manuals are here to help guide you during any restoration, service, or repair project. Being specific to your vehicle make and model, you are sure to have the most accurate information at your fingertips.
Part TypeRepair Manual
Product LineScott Drake Ford Service and Repair Manuals
BrandSCOTT DRAKE
Package Height0.5
Package Width0.5
Package Length11.0
Weight0.12 PG
Part CategoryReplacement Parts
Manual TypeVacuum Schematic
Vehicle MakeFord
Part FitmentDirect Fit
Vehicle ModelMustang
Vendor Part NumberMP-152
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
