Cast Piston Set for 1953-1962 GM 235, 236 ci. Inline 6 Cylinder Engine
InfoVehicle Info Needed
SEALED POWERPART NUMBER: 844-1009P

Cast Piston Set for 1953-1962 GM 235, 236 ci. Inline 6 Cylinder Engine

$32499
ShippingShips on 09/23/2026
Lowest PriceLowest Price Guarantee

GM Pistons
Cast Piston Set
  • 1953-1962 GM 235, 236 ci. Inline 6 Cylinder Engine
  • Bore: 3.5625 (stock)
  • Cast w/FM132 Eutectic Alloy Aluminum
  • Up-Tilt Ring Grooves Improve Piston to Ring Seal
  • Improved Blow-By Control
  • Set of 6

    Sealed Power 1009P Cast Piston Set for 1953-1962 GM 235, 236 ci. Inline 6 Cylinder Engine:

    • Piston Material: Cast Aluminum
    • Bore Diameter: 3.5625 in. (90.5 mm)
    • Oversized: No
    • Top Compression Ring Thickness: 0.0937 in.
    • Second Compression Ring Thickness: 0.0937 in.
    • Oil Ring Thickness: 0.1875 in.
    • Piston Pin Outside Diameter: 0.865 in.
    • Compression Height: 2.062 in.
    • Head Type; Flat Head w/no valve reliefs
    • Pin Offset: 0.078 in.
    • Minimum Clearance: 0.001 in. @ Bottom Of Skirt
      • The value of Speed-Pro's line of cast aluminum pistons are hard to beat for budget or stock-style rebuilds. They are made from high-quality aluminum alloys and feature a carefully controlled casting, heat-treating, and CNC-machining process. And, because they're designed and manufactured to exceed OEM specs, they'll provide improved reliability, performance, and a long service life.
    Part TypePiston
    Product LineSpeed-Pro Cast Pistons
    BrandSEALED POWER
    Package Height4.5
    Package Width9.5
    Package Length13.3
    Weight9.95 PG
    Part CategoryReplacement Parts
    Wrist Pin StylePress-fit
    QuantitySet of 6
    Piston MaterialCast aluminum
    Part FitmentSemi Universal
    Piston StyleFlat top, with no valve reliefs
    Vendor Part Number1009P
    Package Qty1
    Package TypeEA
