Vehicle Info NeededSEALED POWERPART NUMBER: 844-1011P
Pistons Ford 223ci L6 Standard
$31999
Ships on 09/23/2026
Lowest Price GuaranteeFord Pistons
Cast PistonsFord 223ci L6 Bore: 3.625" (Standard) Flat Top Ring Grooves 3/32", 3/32", 3/16" Set of 6
Features:
- Cast with FM132 Eutectic Proprietary Alloy
- Performance & Dependability of Original Equipment Pistons
- High-Quality Aluminum
- Utilizes ISO & QS Certified Manufacturing
- Meets or Exceeds OEM Specifications
Technical Specs: - Material: Cast Aluminum (FM132 Eutectic alloy)
- Bore: 3.6250' (92.1000mm)
- Piston Top: Flat Head - 8.3:1 Comp Ratio
- Compression Height: 1.858"
- Compression Ring Groove: 3/32"
- Second Ring Groove: 3/32"
- Oil Ring Groove Width: 3/16"
- Full Length: N/A
- Pin Size: .9122" O.D. (23.17mm)
- Pin Type: N/A
- Pin Offset: 0.062" (1.575mm)
- Skirt Type: N/A
- Piston Skirt Clearance: N/A
Part TypePiston
BrandSEALED POWER
Package Height4.4
Package Width4.4
Package Length4.4
Weight1.61 PG
Part CategoryReplacement Parts
QuantitySet of 6
Part FitmentDirect Fit
Vendor Part Number1011P
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
