Features:

• Cast with FM132 Eutectic Proprietary Alloy
• Performance & Dependability of Original Equipment Pistons
• High Quality Aluminum
• Utilizes ISO & QS Certified Manufacturing
• Meets or Exceeds OEM Specifications

  Technical Specs:
• Material: Cast Aluminum
• Bore: 3.780' (96.012mm)
• Piston Top: Dish Top, 0.227" Deep x 3.050" Diameter - 8.4:1 Compression Ratio
• Compression Height: 1.835"
• Compression Ring Groove: 5/64"
• Second Ring Groove: 5/64"
• Oil Ring Groove Width: 3/16"
• Full Length: N/A
• Pin Size: 0.9397" O.D. (23.87mm)
• Pin Type: N/A
• Skirt Type: Non-Coated
• Piston Skirt Clearance: N/A
• Notes: Use Piston Ring p/n 844-E240X30 Standard Set; p/n 844-E240K30 Premium Moly Set (Rings Not Included)
