Features:

• Cast with FM132 Eutectic Proprietary Alloy
• Performance & Dependability of Original Equipment Pistons
• High-Quality Aluminum
• Utilizes ISO & QS Certified Manufacturing
• Meets or Exceeds OEM Specifications

  Technical Specs:
• Material: Cast Aluminum
• Bore: 4.3200' (109.700mm)
• Piston Top: Flat Top - 8.0:1 Comp Ratio
• Compression Height: 1.912"
• Compression Ring Groove: 5/64"
• Second Ring Groove: 5/64"
• Oil Ring Groove Width: 3/16"
• Full Length: N/A
• Pin Size: 1.0939" O.D. (27.785mm)
• Pin Type: N/A
• Pin Offset: 0.09" (2.286mm)
• Skirt Type: N/A
• Piston Skirt Clearance: N/A
• Notes: Use Piston Ring p/n 844-E424X Standard Set; p/n 844-E424K Premium Set (Rings Not Included)
