Designed for hydraulic flat tappet camshafts less that .600" lift. Requires use of hardened pushrods.

 Includes:

Fully Assembled Cylinder Heads

Eliminator Intake Manifold

Aluminum Rocker Arms

950 CFM Billet Carburetor

Fuel Line

Intake Gaskets

Specifications:

Camshaft Included: No

Intake Manifold Included: Yes

Fuel Delivery Style: Carbureted

Intake Material: Aluminum

Intake Finish: Polished

Carburetor Quantity: One

Carburetor Included: Yes

Carburetor Choke: None

Carburetor Secondary Type: Mechanical

Carburetor CFM: 950

Carburetor Fuel Inlet: Dual

Intake Style: Dual plane Air Gap

Intake Basic Operating RPM Range: 1500-6,500

Intake Manifold Model: Eliminator Open Air Series

Carburetor Flange: Square bore

Timing Chain and Gears Included: No

Lifters Included: No

Gaskets Included: Yes (Intake Only)

Cylinder Head Style: Assembled

Cylinder Head Material: Aluminum

Cylinder Head Finish: Natural

Combustion Chamber Volume (cc):  65 cc

CNC-Machined Combustion Chamber: No

Intake Runner Volume (cc): 170 cc

CNC-Machined Intake Runner: No

CNC-Machined Exhaust Runner: No

Intake Port Shape: Square

Intake Port Location: Standard

Exhaust Port Shape: Square

Exhaust Port Location: Standard

Spark Plug Style: Stock

Comp. Valve Job: No

Intake Valves Included: Yes

Intake Valve Diameter (in): 2.020 in.

Exhaust Valves Included: Yes

Exhaust Valve Diameter (in): 1.600 in.

Intake Valve Angle: 23 deg.

Exhaust Valve Angle: 23 deg.

Valve Springs Included: Yes

Outside Diameter of Outer Spring (in): 1.450 in.

Damper Spring Included: Yes

Number of Springs Per Valve: Dual

Retainers Included: Yes

Retainer Material: Chromoly steel

Locks Included: Yes

Lock Style: 10 degree

Valve Stem Seals Included: Yes

Valve Stem Seal Style: Positive stop

Rocker Arms Included: Yes

Rocker Arm Studs Included: Yes

Rocker Arm Nuts Included: Yes

Rocker Arm Nut Thread Size: 3/8-24 in.

Guideplates Included: n/a

Guideplate Pushrod Size: n/a

Pushrods Included: No

Valve Covers Included: No

Accessory Bolt Holes Drilled: Yes

Valve Guides Included: Yes

Valve Guide Material: Bronze

Valve Seats Machined: Yes

Valve Seat Machine Style: 3-angle

Valve Seat Material: Ductile iron

Steam Holes Drilled: n/a

Oiling Style: Through the rocker arm rails

Machined for O-Ring: No

Heat Crossover: No

Cylinder Head Bolts Included: No
