Standard Features

   Powers Load IN and OUT

   Mechanical and Dynamic Brake

   Full-metal Planetary Gear-train

   Freespooling Clutch for Fast Wire Rope Payout

   High Efficiency Low Amp Draw Motor

   Heavy Duty Switching Relay Sealed to Protect Against the Elements

   Convenient Handlebar Mounted Low Amp "Roggle" Switch

   Circuit Breaker Protected

   Roller Fairlead

   Performance 12VDC (1st layer on drum)

   Line Pull
   lbs./kg

Line Speed
FPM (m/m)

Motor
Amps 12V

   0

26.9 (8.2)

  15

   500 (227)

13.0 (3.9)

  40

   1,000 (454)

11.5 (3.5)

  60

   1,500 (680)

  9.0 (2.7)

100

   1,800 (816)

  7.5 (2.3)

115

   2,300 (1043)

  5.4 (1.6)

160

   2,500 (1134)

  4.0 (1.2)

180

   3,000 (1361)

  2.0 (0.6)

220

   Specifications

   Rated Line Pull (Single Line)

3,000 lb. (1361 kg)

   Motor

1.1 hp (12V DC)

   Gearing

Dfferential Planetary

   Gear Ratio

153:1

   Freespooling Clutch

Pull and Turn

   Braking

Mechanical and Dynamic

   Wire Rope

3/16" x 50' (4.8mm x 15.2m) with Latched Hook

   Dimensions

12.3"l. x 4.36"d. x 4.5"h.

(322.6mm l. x 110.7mm d. x 114.3mm h.)

   Drum Diameter

1.25" (31.8mm)

   Drum Length

2.9" (73.7mm)

   Weight

15 lb. (6.8 kg)

   Switching Method

Handlebar Mounted Roggle

   Switching Mechanism

Heavy Duty Sealed Switching Relay

   Roller Fairlead

Standard

   Color-Coded Wiring

Yes

   Wireless Remote Control

Optional

   Recommended Accessories

   Accessory Kit

1554

   Wireless Remote System

06212

   Replacement Parts

   Wire Rope

   3/16" x 50' (4.8mm x 15.2m)

1511F

   Roggle Switch

87-14422

   Pulley Block

2227A
