Standard Features

Power Load IN and OUT

Mechanical and Dynamic Brake

Full-metal Gear-train

Freespooling Clutch for Fast Wire Rope Payout

High Efficiency Low Amp Draw Motor

Commercial Grade Integrally Mounted Sealed Contactor

Circuit Breaker Protected

Durable Handheld Remote Switch on 30' Lead

Roller Fairlead

Performance 12VDC (1st layer on drum)

Line Pull
lbs./kg

Line Speed
FPM (m/m)

Motor
Amps 12V

0

27.7 (8.4)

15

1,000 (454)

12.5 (3.8)

70

2,000 (907)

9.0 (2.7)

117

2,500 (1,134)

7.5 (2.3)

155

3,000 (1,361)

4.5 (1.4)

220

Specifications

Rated Line Pull (Single Line)

3,000 lb. (1,361 kg)

Motor

1.3 hp (12V or 24V DC)

Gearing

Differential Planetary

Gear Ratio

159:1

Freespooling Clutch

Lever action

Braking

Mechanical and Dynamic

Wire Rope

3/16" x 60' (4.8mm x 18.2m) with Latched Hook

Dimensions

15.1"l. x 8.7"d. x 6.0"h.

(383mm l. x 221mm d. x 152mm h.)

Drum Diameter

1.625" (41.3mm)

Drum Length

3" (76.2mm)

Weight

38 lb. (17.3 kg)

Switching Method

30' Rubber Handheld Remote

Switching Mechanism

Commercial Grade Contactor

Roller Fairlead

Standard

Wireless Remote Control

Optional

Recommended Accessories

Accessory Kit

1554

Pulley Block

2229A

Mounting Systems (See application chart)

Replacement Parts

Wire Rope

3/16" x 60' (4.8mm x 18.2m)

1511C

Handheld Remote Switch 30' (9.1m)

2774
