Breakdown of Included Items

Dimensions

OBD-II Diagnostic Scanner Comparison Chart

Features:

• Entry-level OBD-II/EOBD (European On-Board Diagnostics) scanner
• For 1996-newer US-based and 2000-newer European-based vehicle makes and models
• Compact mini-size for convenient carrying and storage
• Cost-effective designed with basic OBD-II functions
• Over 7,000 code definitions included within the user manual
• Powered by the OBD-II port, no battery is needed
• durable, anti-skid outer protector
• Supports multiple languages (English, Deutsch, Dutch, French, and Spanish)
• Note:
  • No software updates
  • No live data viewing
  • No ABS, SRS, transmission diagnosis support
  • For 12 V vehicles only

Functions:

• Erase check engine lights (MIL)
• Clear trouble codes
• Reset monitors
• Shows the detailed description of current diagnostic trouble codes (DTC), generic, manufacturer-specific and pending codes
• Automatic VIN retrieval for faster diagnosis
• Inspection/Maintenance (I/M) readiness check for proper emission systems inspection and status
• View freeze frame data from the vehicles operating parameters at the moment a DTC is detected

Scanner Specifications:

• 128x64 backlit pixel display
• 22 in. 16-pin OBD-II port connector
• 32 degrees F (0 C) to 140 degrees F (60 C) operating temperature
• -4 degrees F (-20 C) to 158 degrees F (70 C) storage temperature
• 8-18 V power output
• .33 lbs.
