Breakdown of Included Items for Traxxas 88086-4

Dimensions for Traxxas 88086-4

Traxxas 88086-4 Features:

• Detailed large-scale RC body with authentic decals
• Factory-Installed Pro-Scale Winch
• An extended chassis design with 30 in. full-length steel frame rails - 1.500 mm thick for increased torsional rigidity
• Pre-installed LED lighting kit with (25) total individual LED lights
• Detailed flatbed with adjustable wheel chocks, tie-down bands, and winch
• TQi 2.4GHz 4-channel transmitter Traxxas Link-enabled* and cruise control
• Adjustable steering and throttle sensitivity and endpoints
• Fully waterproof trail-tuned XL-5 HV Waterproof Electronic Speed Control with (5) drive profiles: Sport, Race, Training, Trail, and Crawl
• Titan 21T 550 motor with reverse rotation, internal cooling fan, and preset gear mesh adjustments
• 2-speed high/low range transmission with remote shifting
• Portal Axles improve axle geometry to eliminate torque twist and increase ground clearance
• Full-time shaft-driven 6-wheel drive
• Remote-locking front and rear differentials
• 45-degree steering angle with bump steer
• 3-link front suspension with Panhard bar
• Triangulated 4-link rear suspension
• Adjustable GTS coil-over shocks with silver-anodized aluminum threaded bodies
• 2.200 in. black-chrome big rig wheels with hub inserts
• 2.200 in. Canyon RT all-terrain tires with S1 rubber compound and pre-installed foam inserts
• Sealed ball bearings
• Rust-resistant black oxide-coated hex hardware is used throughout the chassis

Traxxas 88086-4 Notes:

• Accepts NiMH (6–7 cell) and LiPo (2s–3s) batteries - sold separately
• The transmitter requires (4) AA alkaline batteries - NOT included
• Traxxas EZ-Peak Live Charger is recommended - 430-2971

*Traxxas Link Apps:

Replacement Parts:

• For Additional Motors, Light Kits, and Electronic Accessories: Click Here
• For Replacement Body Parts: Click Here
• For Replacement Batteries and Chargers: Click Here
• For Replacement Wheels and Tires: Click Here
• For Replacement Controllers and Transmitters: Click Here
• For Replacement Suspension Components: Click Here

88086-84-BLK supersedes 88086-4-BLK
