Tuxedo Lift Shipping Q&A

Features

• Low profile design under 4 inches with drive-over ramps
• Single point lock release system
• Heavy-duty arm restraints and sturdy base construction
• 2-Stage telescoping swing arms
• Telescoping screw pads
• Includes stackable pad extensions (4) 2 in. and (4) 4 in.
• 21 lockable positions

Specs

• Lifting Capacity: 6,000 lbs. (1,500 lbs. per arm)
• Overall Height: 102 3/8 in.
• Overall Width: 45 3/16 in.
• Overall Length: 101 9/16 in.
• Minimum Ceiling Height: 9 ft.
• Swivel Pad Low Pad Height: 3 15/16 to 6 5/16 in.
• Maximum Lift Height: 72 in.
• Drive Over Height: 3 15/16 in.
• Arm Main Side Reach: 19 11/16 to 26 in.
• Arm Off Side Reach: 24 5/8 to 34 in.
• Motor: 2.500 HP
• Power: 115 V, Single Phase
• Weight as Shipped: 1,850 lbs.
