Vehicle Info NeededUNITED ENGINE MACHINEPART NUMBER: 648-IC744.030
ICON Premium Forged Small Block Chrysler 408 ci Piston Set 4.030 in. Bore
$68484
Ships Tomorrow
Lowest Price GuaranteeChrysler 408ciFlat Top Pistons Use w/6.123" Connecting Rods
- Small Block Chrysler 360 ci Forged Pistons
- Flat Top 2V
- 4.030 in. Bore (+.030 in. )
- 6.123 in. Connecting Rod
- 4.000 in. Crank Stroke
- 5 cc Head Volume
- Comp. Ratio: 12.4/60 cc; 11.5/65 cc; 11.0/70 cc
- Set of 8
Technical Specs: - Alloy: Premium High Ductility 2618
- Bore: 4.030"
- Crankshaft Stroke: 4.000"
- Connecting Rod Length: 6.123"
- Deck Height: 9.599'
- Compression Height: 1.465'
- Pin Size: 0.9842' x 2.750"
- Pin Location: Centered
- Flat Top: 2 Valve Reliefs
- Effective Head Volume: 5cc
- Intake Valve Relief: 0.243' Depth / 2.200' Diameter
- Exhaust Valve Relief: 0.232' Depth / 1.720' Diameter
- Top Landing Height: 0.222'
- Ring Grooves: 1/16' Top; 1/16' Middle; 3/16' Bottom
- Gram Weight: 507/118
- Compression Ratio: 12.4:1 w/60cc Heads; 11.5:1 w/65cc Heads; 11.0 w/70cc
Part TypePiston
BrandUNITED ENGINE MACHINE
Package Height3.7
Package Width9.3
Package Length18.4
Weight11.92 PG
Part CategoryPerformance Parts
Part FitmentSemi Universal
Vendor Part NumberIC744.030
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
